FILLING THE VOID

The burbling-pop of the quickshifter encourages you to wind on a few more revs for the next up-shift. Riding the torque curve, confidently firing out of corners. This is a riding experience defined by its easy-going rawness. But when the empty road calls for it – when you need to wrestle the bars and scrub the tyres, the SVARTPILEN 701 will happily oblige.

ENGINE

The SVARTPILEN 701 is powered by a modern 692.7 cc liquid cooled, single-cylinder engine that features the latest design and electronics technology. With a peak horsepower of 55 kW (75 hp) and 72 Nm of torque at 6750 rpm, there is no doubting this motorcycle’s performance potential. The electronic fuel injection is operated by a ride-by-wire system and delivers immediate, sharp and refined power, controlled by the standard traction control system. Featuring some of the latest technical solutions, such as a standard up & down easy shift, this engine delivers exceptional ride-ability. Produced using innovative production processes and the highest quality materials, premium reliability and efficiency is ensured. This quality also results in conveniently long 10,000 km service interval.

BRAKES

The SVARTPILEN 701 is fitted with hydraulic BREMBO brake callipers, which are manufactured to the highest standards and, in combination with 320 mm front and 240 mm rear perforated steel discs, deliver controllable and confident braking performance. The SVARTPILEN 701 is also fitted with a state-of-the-art BOSCH ABS system, ensuring the highest level of safety in varying braking conditions.

SUSPENSION

The WP APEX suspension on the SVARTPILEN 701 is made to exacting standards, ensuring the highest level of quality and craftsmanship. The front features upside down 43 mm forks with a split damping function, while the rear features a monoshock, connected via a linkage to the swingarm. The high-quality components are adjustable for constantly changing urban environments.

Model Specification


  • Engine
    Engine Type

    1-cylinder, 4-stroke engine

    Displacement

    692.7cc

    Starter

    Electric starter

    Engine Management System

  • Frame
    Bore

    105mm

    Stroke

    80mm

    Frame Design

    Steel trellis frame, powder coated

    Chain

    X-Ring 5/8 x 1/4

    Steering head angle

    65 degrees

    Total fuel tank capacity approx.

    12 litres

    Weight without fuel approx.

    161kg

  • Transmission
    Transmission

    6 speed

    Clutch

    ATPC slipper clutch, hydraulically actuated

  • Suspension
    Suspension travel Front

    150mm

    Suspension travel Rear

    150mm

    Front Suspension

    Rear Suspension

  • Wheels
    Brake system Front

    Brembo four piston radial fixed calliper

    Brake system Rear

    Brembo single piston floating calliper

    Brake discs - diameter Front

    320mm

    Brake discs - diameter Rear

    240mm

  • Dimensions
    Ground clearance (unloaded)

    164mm

    Seat height (unloaded)

    835mm

  • Performance
    Power

  • Brakes
    ABS System
